2133 Thermocouple Input Expansion
2133 Thermo Input Expansion
DSENet® RTD/Thermocouple Input (8) Expansion Module
The DSE2133 is an RTD/thermocouple input expansion module providing 8 additional inputs to the control module. Up to 4 DSE2133 modules can be linked together to provide up to 32 additional inputs.
OVERALL SIZE
165 mm x 76 mm x 49 mm (6.5” x 3.0” x 1.9”)
WEIGHT
0.22kg
PRODUCT VARIANTS
2133-01 - 2133 RTD/Thermocouple Input Expansion Module
The DSE2133 Input Expansion Module is used in conjunction with supported DSENet controllers to provide 8 additional configurable inputs.
Up to four modules can be linked together to provide up to 32 additional inputs.
The inputs can be configured as RTD or Thermocouple inputs in the ‘host controller’.
The DSE2133 has an ID switch to enable identification when multiple modules are used.
LED indication is provided for Power On or Link Lost
KEY FEATURES
- Power on/Link lost LED
- 4 modules can be connected to 1 host controller at a time
- 8 inputs configurable for J-type/K-type thermocouple, PT 100, 3 wire RTD sensors
- Works up to 1.2 km (0.75 miles) from the host module
- Terminal strip connection for quick and easy set-up
KEY BENEFIT
- Ideal for applications where temperature monitoring is critical eg. engine temperature, enclosure temperature, etc.
